KNX DALI GATEWAY BROADCAST - 4 CHANNELS - TUNABLE WHITE DT6, DT8

The IC04B01DAL DALI Gateway is a 4-channel single-master controller for controlling electronic ballasts with a DALI® interface via the KNX® installation bus. It supports ballasts according to IEC 62386-102 ed1 (DALI1) as well as devices according to IEC 62386-102 ed2 (DALI2). The device converts switching and dimming commands from the connected KNX system into corresponding DALI telegrams, or status and event information from the DALI bus into KNX telegrams. The IC04B01DAL has four DALI outputs. Up to 32 ECGs can be connected to each output. The ECGs connected to a channel are controlled simultaneously via broadcast telegrams. The power supply required for the connected ECGs comes directly from the device. Additional DALI power supplies are not required. The device is available in a 4TE wide DIN-rail housing for direct installation in an electrical distribution board. The bus connection is made via a bus terminal. Mains and DALI cables are connected via screw terminals on the device. The KNX communication interface is included. Main functional features: • 4 independent DALI channels for broadcast control • Simultaneous control of up to 32 ECGs per channel • No DALI commissioning or identification of the DALI luminaires required • Extensive control of the channels via various KNX communication objects • Colored light control with support for Device Type 8 (DT-8) ballasts and control via communication objects • Colored light control depending on ballast sub-type: • Color temperature (DT-8 Sub-Type Tc) • RGB (DT-8 Sub-Type RGBWAF) • HSV (DT-8 Sub-Type RGBWAF) • RGBW (DT-8 Sub-Type RGBWAF) • Automatic change of the color temperature depending on the light value (DimmTo-Cold) • Broadcast objects for controlling all connected ECGs simultaneously • Various operating modes for groups such as continuous operation, night operation, staircase operation (timing) • Timer for switch-on and switch-off delays • Integrated operating hours counter for each channel with alarm when the service life is reached • Individual fault detection of lamps and ECG faults for each channel with alarm via communication objects • Scene module for up to 16 scenes, which can be assigned to KNX scenes 1..64 • “Energy-saving function” allows the ECG power supply to be switched off when the light is switched off via additional switching actuators • Manual operation via operating buttons on the device • Signaling of error states and status diagnostics via LEDs on the device.
