KNX-BACnet GATEWAY - 250 points

The IC01E01BAC Gateway serves as an interface between KNX and BACnet. The parameterized KNX communication objects are translated as BACnet objects and can therefore communicate in the BACnet world. BACnet Clients can either register via a so-called COV-Subscription and are automatically informed about KNX events or they use the Read Property Service to query the status of the objects as required. The module comes in a 4 unit DIN rail housing and can be installed in a standard distribution board. The configuration and commissioning of the device requires the use of the ETS program, (Engineering Tool Software) V4 or later, downloadable from the website: www.eelectron.com. The KNX communication interface is included. Main characteristics: • Diagnostic functions supporting supervisory management are implemented. • 250 objects available. • Off/on objects are translated as binary, while others become analogue objects (Input, Output, Value). • Web Server to display the configuration and status of the objects. • Additional safety extra-low voltage of 24VDC required
