CAPACITIVE SWITCH DOOR PANEL - WHITE

The KNX® 9025 capacitive doorpanel is a capacitive switch with RGB led bar; it is used in combination with the glass/plexiglass covers available in black or white; these covers can be ordered in a specific version for the required application. The upper part of the cover can have a personalized, backlit room number; the lower part provides a key for the bell function, one for the ‘do not disturb’ function (DND) and one for the ‘make up room’ function (MUR). 2 other buttons customizable on request are available. Device includes a 2 stage Room Temperature Controller with integrated PI to control heating and cooling equipments, valves, 2 and 4 pipes fan coils; etc.. Device has an embedded temperature sensor and a rear 2 poles connector configurable as digital or analog input; It’s possible to connect an additional NTC temperature probe (codes TS01A01ACC, TS01B01ACC, TS01D01ACC - not included) to perform a direct temperature measurement. Device has a RGB led bar on the front side in order to visualize feedbacks or other values available over the KNX bus (function available on the RGB range). The 9025 KNX® range is mounted in 2 or 3 modules box and is compliant with main standards (British, German, Italian, etc).
