4.3” KNX CAPACITIVE TOUCH PANEL - IP CONNECTIVITY - DOOR PHONE - GLASS - BLACK

The touch panels TP43M01KNX-GL, TP43M11KNX-GL, TP43I21KNX-GL are advanced room controllers with a 4,3” capacitive touch display designed for visualisation and control of KNX installations. They are available in white or black GLASS finish, and can be installed in portrait or landscape mode. Function highlights: • Up to 96 control functions, organized in 12 configurable pages • User editable favorites page • Custom background images • Weekly time schedules: up to 96 channels, 4 programs / channel • Alarm monitoring: up to 96 alarms, with event log • Touch gestures: Up to 5 quick actions without leaving power saving mode • Internal scene controller • Two independent thermostats • Four multi-function inputs, individually configurable as binary or temperature probe inputs • Built-in temperature sensor (not supported in TP43I21KNX-GL) • Real-time clock (RTC) with backup battery • Integrated KNX bus coupling unit • Ultra-low power consumption The TP43M11KNX-GL, and TP43I21KNX-GL models feature an Ethernet connector, and support remote control from smartphones and tablets through the eTouch-App. The TP43I21KNX-GL model also doubles as an indoor video door phone monitor, and supports IP camera visualisation. The device is mounted in 2 or 3 modules box and is compliant with main standards (British, German, Italian).
