UNIVERSAL MODULE 24 OUT PLUS

Device BO24F01KNX is a DIN rail EIB / KNX® actuator with 24x16A – 230V AC relay outputs. The outputs can be configured as: • 24 outputs for light / load control • 24 channels for valve in PWM (solenoid actuators) • 12 channels for roller shutter / venetian control • 12 channels for 3-point valve control • 6 fan coil actuators 2-pipes • 4 fan coil actuators 4-pipes It is also possible to combine 3, 4 or 5 relays with logic interlock for up to 4-pipe / 3-speed fan coil control or combine groups of relays (up to 6) for special function using logic interlock. The device includes frontals buttons for switching local relays and LEDs to indicate operation. Device is equipped with KNX® communication interface and is intended for installation on DIN rail in LV distribution switchboards.
