UNIVERSAL MODULE 16 OUT PLUS + SD CARD

Devices IO16F01KNX and BO16F01KNX are DIN rail EIB / KNX actuators with 16x16A - 230V AC relay outputs; device IO16F01KNX also includes 16 inputs for dry contacts (potential-free). The outputs can be configured as: • 16 outputs for light / load control • 16 channels for valve in PWM (solenoid actuators) • 8 channels for roller shutter / venetian control • 8 channels for 3-point valve control • 4 fan coil actuators 2-pipes It is also possible to combine 2 or 3 relays with logic interlock for 4-pipe / 3-speed fan coil control or combine groups of relays (up to 8) for special function using logic interlock. The device includes manual buttons for switching local relays and LEDs to indicate operation. The inputs can be connected to pushbuttons, switches, or be configured as outputs to activate individual signalling LEDs (see LED eelectron code LD00A01ACC / LD00A11ACC) and can be used for on / off, dimming, shutters or venetian blinds / scenarios, sequences, step-by-step commands, etc. 4 inputs (of the 16) are configurable as analogue for the connection of NTC temperature probes (see probes eelectron code TS00A01ACC / TS00B01ACC) with which to send 4 temperature measurements on the bus and manage a simple on / off controls (e.g. towel heater). It is also possible to enable 2 complete thermostat modules if inputs 3 ÷ 8 and 11 ÷ 16 are not used; each thermostat module manages 2 stages with integrated PI controller for driving heating and cooling equipment, valves, 2 and 4-pipe fan coils, etc. Device is equipped with KNX communication interface and is intended for installation on DIN rail in LV distribution switchboards
