MDT AZI-0316.03 - Switch Actuator 3-fold, 4SU, MDRC, 16/20 A, 230 V AC, C-load, 200µF, power measurement

Switch Actuator 3-fold, 4SU, MDRC, 16/20 A, 230 V AC, C-load, 200 µF, power measurement. Industrial version with bistable relays.
Comprehensive application. Integrated True RMS current measurement and voltage measurement. True active power meter (Wh / kWh). Current measurement range 10 mA to 20 A. Active power-, reactive power-, current- and voltage values. Push Button for manual operation and LED indicator for each channel. Time functions (switch-on/switch-off delay, staircase light function). Inputs and Outputs for threshold values. Priority / forced operation with automatic release time. Logical linking of binary data, 8 scenes per channel. Operating hours meter. Extended status functions (inverted, cyclic, when locked). Adjustable behaviour on bus voltage failure / -return. All L-connections separated, 4 mm² / 2 x 2,5 mm² connection terminals. 3 year warranty.
